JPF 6" Judo Profi Baskwash Water Filter

JUDO PROFI 5"- 8"

Model JPF JPF JPF

Pipe Size 5" 6" 8"

Max. fl ow rate m3

/h (gpm) 100 (440) 150 (660) 200 (880)

Min./Max. operating pressure psi (kPa) 22 - 145 (150 -1000) 22 - 145 (150 -1000) 22 - 145 (150 -1000)

Pressure loss aft er backwash psi (kPa) 2.9 (20) 2.9 (20) 2.9 (20)

Standard mesh size mm (microns) 0.1 (100) 0.1 (100) 0.1 (100)

Maximum ambient temperature °C (°F) 30 (86) 30 (86) 30 (86)

Maximum water temparature °C (°F) 30 (86) 30 (86) 30 (86)

Weight approximate kg (lbs) 84 (185) 137 (302) 185 (408)

Order No. 8290015 8290016 8290017

Equal to Ottorep8255
